Data rate: uplink 10.3125/1.25Gbps，downlink 10.3125/1.25Gbps application, support 10.3125/10.3125Gbps symmetric 10GEPON ONU ,10.3125/1.25Gbps asymmetric 10GEPON ONU and 1.25/1.25Gbps EPON ONU
1577nm continuous-mode EML DFB laser /1490nm continuous-mode DFB laser transmitter and 1270nm and 1310nm burst-mode APD-TIA receiver
10 Gigabit Small Form Factor Pluggable package with SC/UPC Connector
0～+70℃ Operating Temperature, -40～+85℃ Storage Temperature
+3.3V power supply
Digital diagnostic monitoring interface
Digital burst RSSI function to monitor the input optical power level
LVTTL transmitter disable control
Very low EMI and excellent ESD protection
